PATROL C093 CARBON 2022
PATROL C093 CARBON 2022
Regular price
$3,599.00 AUD
Regular price
Sale price
$3,599.00 AUD
Unit price
per
XC CARBON HARDTAIL
These hardcore hardtails might look like XC whips, but their geometry is pure enduro. These sleek carbon frames use new internal cable routing through the headtube and hidden compartment in the downtube for a spare gear hanger.
“The Patrol C091 is a comfortable XC bike, a hoot at the trail centre and more capable than a gravel bike for long-distance touring. Forget about enduro, trail, down-country, it’s good to see a bike that represents what a mountain bike should be, a great all-around off-roader.” - SINGLETRACK
Specifications
| Enduro | |
|---|---|
| PATROL C092 | Carbon 29er hardtail |
| WheelsFront | |
| Rear | PATROL, alloy, 32h |
| Rear Tyre | VEE TIRE Mission, 29×2.30 |
| Front | PATROL, alloy, 32h |
| Front Tyre | VEE TIRE Mission, 29×2.30 |
| - | |
| - | |
| Frameset | |
| Frame | PATROL 09 carbon, 12×148 mm Boost |
| Drivetrain | |
| Chainrings | SHIMANO Deore MT510-1 |
| Shift Levers | SHIMANO Deore M5100 |
| Crankset | - |
| Chain | - |
| Rear Derailleur | SHIMANO Deore M5100-1 |
| Bottom Braket | - |
| Cassette | SHIMANO Deore M5100-11 |
| Cockpit | |
| Seatpost | KS KSP900-I remote, 31.6mm, 150mm (S/M) – 175mm (L/XL) |
| Saddle | - |
| Stem | - |
| Handlebars | - |
| Grips | - |
| Brakes | |
| Rear Brake | SHIMANO MT200 |
| Front Brake | SHIMANO MT200 |
| Suspension | |
| Fork | X-FUSION RC32, 130mm travel, TA 15×110 |
| Rear Shock | None |
* Specifications are subject to change without notice.
Geometry
| Small | Medium | Large | X-Large | |
|---|---|---|---|---|
| 1 Head Tube Angle | 67° | 67° | 67° | 67° |
| 2 Head Tube Length | 105mm | 110mm | 110mm | 115mm |
| 3 Top Tube Horizontal | 606mm | 631mm | 655mm | 685mm |
| 4 Reach | 425mm | 450mm | 475mm | 500mm |
| 5 Standover | 704mm | 708mm | 738mm | 780mm |
| 6 Stack | 630mm | 630mm | 635mm | 639mm |
| 7 Seat Tube Length | 400mm | 420mm | 460mm | 510mm |
| 8 Seat Angle | 74° | 74° | 74° | 74° |
| 9 Bottom Bracket Height | 311mm | 311mm | 311mm | 311mm |
| 10 Bottom Bracket Drop | -62.5mm | -62.5mm | -62.5mm | -62.5mm |
| 11 Chainstay Length | 440mm | 440mm | 440mm | 440mm |
| 12 Wheelbase | 1157mm | 1182mm | 1206mm | 1234mm |
